Model No.

SMI-160DL-1000

SMI-160DL-1200

SMI-160DL-1500

SMI-160DL-1800

External Size (W X D X H)

1000 X 880 X 2140mm

1200 X 880 X 2140mm

1500 X 940 X 2140mm

1800 X 940 X 2140mm

Internal Size (W X D X H)

910 X 690 X 740mm

1110 X 690 X 740mm

1410 X 690 X 740mm

1710 X 690 X 740mm

Work Surface Height

900mm

Max. Opening

650mm

Air Velocity

0.25 to 0.35m/s

Airflow Volume

105 m³/h

325 m³/h

415 m³/h

Noise

≤55dB(A)

Fluorescent Lamp

16W X 2

16W X 3

UV Lamp

Emission of 253.7 nanometers for most efficient decontamination

Blower

Built-in centrifugal blower, speed adjustable

Front Window

Acrylic window; Manual; reversal design;

Power Supply

AC220V±10%, 50/60Hz; 110V±10%, 60Hz

Consumption

400W

500W

Material

Exterior

Cold-rolled steel with antibacterial powder coating.

Side Window

Acrylic Window

Work Table

Chemical resistant phenolic resin

Chemical Filter

2 Nos.

4 Nos.

Stand Accessories

Fluorescent Lamp, Base cabinet Total load of 2 waterproof sockets: 500W

Optional Accessory

Water tap, Gas tap, Water sink, UV Lamp, Electric height, Adjustable base stand, HEPA Filter

Gross Weight

290Kg

310Kg

380Kg

410Kg

Package Size (W X D X H)

1140 X 1040 X 2350mm

1350 X 1040 X 2350mm

1650 X 1110 X 2350mm

1950 X 1110 X 2350mm
