Cryostat Microtome SMI-3010S

CLICK TO SCAN

JINDAL cryostat microtome is designed for sectioning of natural tissue. These are specially designed for clinical and research operations. Sections have the high resolution of cytological details required for pathological diagnosis, histochemistry, fluorescence, biochemistry, microscopy etc. Technologies are simple and easy to learn.

Features

  • Large Spacious Stainless steel cryo chamber
  • Antimicrobial powder coating with galvanized steel sheet construction
  • Motorized specimen feed coarse advance with specimen retraction
  • CFC free refrigerant with noiseless compressor to achieve low temperatures up to –350C
  • Heated sliding glass door to prevent condensation
  • Microprocessor based touch screen operation
  • Automatic & manual hot gas defrosting
  •  Easy selection from cutting to trimming by touch of a button
  • Adjustable cutting angle
  • Mounted on castors for easy movement
  • UV sterilization which can be activated by touch of a button
  • Ergonomic design blade holder with finger guard for safety & anti roll device
  • Enclosed Drainage system
  • Encapsulated splash protected microtome
  • User friendly menu with section counter
  • Power saving refrigeration system
  • LED illumination for the cryo chamber
Previous
Next
Enquire Now

Modular Design Control System

  • Chromatic LCD touch screen for user friendly operation
  • Hibernation automatically/manually, wake up in 15 minutes
  • UV Sterilization at touch of a button
  • Peltier cooling station for quick freezing of specimens
  • Section thickness totalizer with section counter
  • Slow & fast speeds of specimen feed forward & reverse

Microtome

  • Smooth & light handwheel with locking device lever
  • X-Y-Z 80 specimen orientation triaxially adjustable
  • Precise durable roller guides made in Germany ensures easy sectioning of hard tissue samples & provides smooth movement
  • Adjustable retraction & can be turned off

Cryo Chamber

  • Large spacious stainless steel chamber with large freezing shelf to hold up to 20 specimen discs
  • With waste tray & instrument rack
  • Heat Extractor in quick freeze shelf

Disposable Blade Holder

  • Designed to use both High & low profile blades
  • An anti-fatigue cam lock ensures blades clamp tight
  • The blade holder can move laterally for safety & to ensure full use of the blade
  • Glass anti roll device to adjust the angle & gap with the pressure plate
  • Steel push rod to eject the blade

Range Of Section Thickness

  • 0.5um to 100um
  • 0.5um – 1um in increments of 0.5um
  • 1um – 10um in increments of 1um
  • 10um – 20um in increments of 2um
  • 20um – 50um in increments of 5um
  • 50um – 100um in increments of 10um

Range Of Trimming Thickness

  • 0 to 500um in increments of 5um
  • 0um – 20um in increments of 2um
  • 20um – 50um in increments of 5um
  • 50um – 100um in increments of 10um
  • 100um – 500um in increments of 50um

Technical Data

Product
Cryostat Microtome
Model No.
SMI-3010S
Temperature of Cryo Chamber
Adjustable Up to -35°C
Temperature of Quick Freeze Shelf
Up to -45ᵒC
Number of Freezing Stations
20
Number of Peltier Cooled Freeze Stations
Up to -60ᵒC:2
Motorized Coarse Feed
Slow 600um/sec , Rapid 900um/sec
Total Specimen feed
28mm
Vertical Stroke
60mm
Maximum Specimen Size
55 x 55mm
Refrigeration Capacity
690W
Refrigerant
R404A , 300g±5g
Input Power
650 VA
Net weight
150Kg
Designed to Operate On
220V/50Hz AC Supply or 110V/60Hz AC Supply
Defrost
1 automatic defrost cycle per 24hr/manual (duration 12 minutes)
Dimensions of the Machine
780mmL (650mm without handwheel) x 700mmW x 1152mmH

Optional Features

Vacuum attachment to prevent rolling of sections
