Cryostat Microtome with Vacuum Attachment SMI-3010VA

CLICK TO SCAN

JINDAL Cryostat Microtome  is designed for sectioning natural tissues. These are specially designed for clinical and research operations. Sections have the high resolution of cytological details required for pathological diagnosis, histo-chemistry, fluorescence, biochemistry, microscopy etc. Technique is simple and easy to learn.

The unique dual compressor cryostat is equipped with a double cooling circuit which allows specimen cooling separate from the cryo chamber & the freezing shelf. The user can set the temperature of the specimen independent from the cryochamber. Cryostat microtome has a universal open-topped body. Cryostat has a complete Nano-silver protected & disinfected body which acts as an effective germicide.  Microtome has additional independent quick-freezing stations with Peltier cooling technology & -40°C adjustable temperature reaching for quick cooling of specimens.

The unique dual compressor cryostat is equipped with a double cooling circuit which allows specimen cooling separate from the cryo chamber & the freezing shelf. The user can set the temperature of the specimen independent from the cryochamber. Cryostat microtome has a universal open topped body. Cryostat has a complete Nano-silver protected & disinfected body which acts as an effective germicide.  Microtome has additional independent quick-freezing Stations with peltier cooling technology & -40°C adjustable temperature reaching for quick cooling of specimens.

At a Glance

  • Vacuum for stretching of the tissue sections and suction of cutting debris
  • Automatic error coding system
  • Mounted on castors for easy movement
  • Easy selection from cutting to trimming by touch of a button
  • Separate compressor for specimen cooling up to -35°C
  • Universal blade holder for palm rest & finger guard
  • Independent temperature setting at -40°C of specimen holder
  • Manual trouble shoots elaborate enough for explain & direct the actions in all error codes
  • Antimicrobial powder coating with galvanized steel sheet construction
  • Certified UV illumination disinfection system
Previous
Next
Enquire Now

Features

  • Automatic microtome sectioning
  • Adjustable cutting angle
  • Enclosed Drainage system
  • Bright white illumination for the cryo chamber
  • Automatic hot gas defrosting cycle with safe drainage and filtering system for waste
  • User friendly menu with section counter
  • Encapsulated splash protected microtome
  • Large Spacious Stainless steel cryo chamber
  • LED Display
  • Heated sliding glass window to prevent condensation
  • Control panel with membrane-protected buttons and locking function
  • Motorized specimen feed coarse advance with specimen retraction
  • CFC free eco-friendly refrigerant with noiseless compressor.
  • Mechanical & electronic emergency brake hand wheel lock

Modular Design Control System

  • UV Sterilization at touch of a button
  • Section thickness totalizer with section counter
  • Peltier cooling station for quick freezing of specimens
  • LED display for real time parameters
  • Slow & fast speeds of specimen feed forward & reverse

Microtome

  • Automatic specimen retraction on return stroke
  • X-Y-Z axis 360° specimen orientation at zero position
  • Smooth & light section cutting by hand wheel with manually and motorized.
  • Hand wheel brake applied anytime
  • Manual cutting wheel on right side

Cryo Chamber

  • With waste tray & instrument rack
  • Large spacious stainless-steel chamber with large freezing shelf to hold up to 20 specimen discs

Accessories

  • 5KVA UPS for power backup with 1-hour backup
  • Disposable blades
  • Different sizes of Chucks
  • Disposable blade carrier for high profile blades
  • Fluorescent Lamps
  • Freezing Shelf
  • Cryostat Oil & Cleaning spray with brush
  • Tool set box

Disposable Blade Holder

  • Steel push rod to eject the blade
  • Designed to use both High & low profile blades
  • An anti-fatigue cam lock ensures blades clamp tight
  • Glass anti roll device to adjust the angle & gap with the pressure plate
Range Of Section Thickness
0.5µm – 1µm
In increment of 0.5µm
1µm - 10µm
In increment of 1µm
10µm – 20µm
In increment of 2µm
20µm – 50µm
In increment of 5µm
20µm – 100µm
In increment of 10µm
Range of Trimming Thickness
0µm – 20µm
In increment of 2µm
20µm - 50µm
In increment of 5µm
50µm – 100µm
In increment of 10µm
1000µm – 500µm
In increment of 50µm
20µm – 100µm
In increment of 5µm

Technical Data

Product
Cryostat Microtome with Vacuum Attachment
Model No.
SMI-3010VA
Vacuum
Stretching of the tissue sections and suction of cutting debris
Temperature of Cryo Chamber
Adjustable -10°C to -35°C
Temperature of Specimen
Up to -50°C
Temperature of Quick Freeze Shelf
Up to -45ᵒC
Number of Freezing Stations
20
Number of Peltier Cooled Freeze Stations
Up to -60ᵒC:2
Motorized Coarse Feed
Slow 300µm/sec: FAs 900µm/sec
Total Horizontal Specimen Size
25mm
Vertical Stroke
55mm
Maximum Specimen Size
50 x 80mm
Refrigeration Capacity
690W x 2
Refrigerant
R404A , 300g + 5g
Input Power
1300 VA
Net weight
200Kg
Designed to Operate On
200V/50Hz Ac Supply or 110V/60Hz Ac Supply
Defrost
1 automatic defrost cycle per 24hr/manual (duration 12 minutes)
Dimensions of the Machine
Length: 780mmL (705mm without handwheel), Weight : 700mm, Height : 1152mm
