Home ≫ Heating & Environment >Magnetic Stirrers>Modular Magnetic Stirrer SMI-SH
CLICK TO SCAN
|
Model
|
SMI-SH-2A
|
SMI-SH-2B
|
SMI-SH-2
|
SMI-SH-3A
|
SMI-SH-3B
|
SMI-SH-3
|
|---|---|---|---|---|---|---|
|
Max. Volume (mL)
|
-
|
2000
|
2000
|
-
|
5000
|
5000
|
|
Speed (r.p.m)
|
-
|
100~2000
|
-
|
100~2000
|
||
|
Working Time
|
Continuous
|
|||||
|
Minimum Revolution (r.p.m)
|
-
|
100
|
-
|
100
|
||
|
Max. Temp (℃)
|
380
|
-
|
380
|
-
|
380
|
|
|
Exterior
|
Cast aluminium, Surface spraying
|
|||||
|
Plate Size(mm)
|
120×120
|
170×170
|
||||
|
Driving Mode
|
-
|
Motor
|
-
|
Motor
|
||
|
Motor Power (W)
|
-
|
10
|
-
|
20
|
||
|
Heating Power(kW)
|
0.18
|
-
|
0.18
|
0.5
|
-
|
0.5
|
|
Continuous Operation
|
Yes
|
|||||
|
Setting Mode
|
Scale
|
|||||
|
Speed Display Mode
|
-
|
Scale
|
-
|
Scale
|
||
|
Timer
|
No
|
|||||
|
Operation function
|
No
|
|||||
|
Sensor
|
No
|
|||||
|
Exterior Size(W*L*H)(mm)
|
200×120×90
|
265×185x190
|
||||
|
Packing Size(W*L*H)(mm)
|
250×180×120
|
280×210×150
|
||||
|
Plate Size (mm)
|
120×120
|
170×170
|
||||
|
Plate Load
|
3Kg
|
10Kg
|
||||
|
Power Supply (50/60Hz) current Rating
|
110V/220V Single Phase
|
|||||
|
NW/GW (Kg)
|
1.9/3
|
2.2/3.4
|
||||
Product Brochure Link here
