Semi Automatic Microtome (Ergonomic Design) SMI-325SNMDE

Home ≫Histopathology > Microtomes >Semi Automatic Microtome (Ergonomic Design) SMI-325SNMDE

Semi Automatic Microtome (Ergonomic Design) SMI-325SNMDE

CLICK TO SCAN

Description

Jindal developed the first semi automatic microtome in BHARAT in the early 2000s. Ever since numerous innovations and technical expertise have been incorporated into this machine. It is a latest ergonomic modular humanized design that ensures smooth rotation and sectioning, high – precision and maintenance-free seamless experience. Unique specimen location, accurate blade holder , convenient handwheel locking device, enable efficient operation , high- precision and safer sectioning . Optimized internal mechanism improves the rigidity of the instruments. This machine is designed for frequent and high-precision tissue sectioning in hospitals.

Previous
Next
Enquire Now

Detailed Images

Features

  • Automatic timing lubrication system
  • Automatic shifting between rocking mode and rotation mode during sectioning
  • Specimen retraction function can be switched on/off
  • Handwheel is lockable in any position
  • Precision specimen orientation with clear zero reference point
  • Adjustable blade angle ensures ease of operation
  • Foldable handle in the back of microtome for convenient moving
  • Non stick coating plate
  • Auto hibernation : Auto sleep mode puts the screen to sleep after 15 minutes when not in use to save power
  • Instant display of horizontal specimen movement , sound alert at extreme position
  • Quick change of various tissue clamps
  • Light and noise free rotating
  • Perfect performance with hard tissue sectioning
Range Of Section Thickness 0.25 -100μm
0.5µm - 5µm
In increment of 0.5µm
5µm – 20µm
In increment of 1µm
20µm – 50µm
In increment of 5µm
50µm – 100µm
In increment of 10µm
Range of Trimming Thickness 1-600μm
1µm – 10µm
In increment of 1µm
10µm - 20µm
In increment of 2µm
20µm – 50µm
In increment of 5µm
50µm – 100µm
In increment of 10µm
100µm – 600µm
In increment of 50µm

Technical Data

Object Feed

24 ±1mm

Vertical Specimen Stroke

70 ±1mm

Specimen Orientation

Horizontal 80 , Vertical 80

Specimen Retraction

5-100μm starting from 5μm (in increments of 5μm) (It can also be turned off)

Electric Coarse feed

20μm / click and 100μm/S

Blade holder base movement

±24mm

Maximum Specimen Size ( L X H X W)mm

50 X 60 X 40

Net Weight

31.5Kg.

Gross Weight

58Kg.

Work Temperature

+100 C to +350  C

Work Humidity

<80 % , no condensation water

Nominal Supply Voltage

100 to 240V AC

Nominal Frequency

50/60 Hz

Power Draw

70W
