This product is ideal for applications in environmental protection, sanitation, epidemic prevention, drug inspection, agriculture, aquaculture, and various scientific research fields. It is also well-suited for use in universities and production departments. Designed as a specialized constant temperature device, it supports water body analysis, BOD determination, cultivation and preservation of bacteria, molds, and microorganisms, as well as plant cultivation and breeding experiments. Moreover, setting the temperature between 20–37°C enables it to prevent the crystallization of mannitol solutions
The refrigeration system features a new fluorine-free design, promoting environmental protection.
Includes a parameter memory function to automatically resume operation after power restoration.
The inner chamber has a circular arc design, making it easy to clean.
Equipped with Castors wheels , movable shelves with adjustable spacing for flexible storage.
Temperature is controlled using advanced microcomputer technology, ensuring precision and reliability. The liquid crystal display shows the current operating status in real time.
Operated via a light-touch adjustment switch, offering smooth and flexible operation. An over-temperature alarm device is also included for added safety.
A built-in fan creates forced convection, ensuring uniform temperature distribution within the working chamber.
The outer body is made of high-quality steel plate with a sprayed surface, while the inner chamber is crafted from high-grade stainless steel for durability and corrosion resistance.
An internal lighting system is included for convenient observation.
The chamber door features magnetic sealing and a hollow glass observation window, providing excellent sealing and easy closure. The window allows direct observation of the culture inside the chamber.
Equipped with a power socket to support BOD testing equipment, oscillators, and other small instruments used within the incubator.
Model | SMI-OIBI-80 | SMI-OIBI-100 | SMI-OIBI-150 | SMI-OIBI-200 | SMI-OIBI-250 | SMI-OIBI-300 | SMI-OIBI-400 |
Capacity(L) | 80 | 100 | 150 | 200 | 250 | 300 | 400 |
Temperature Control Range | 0 to 65℃ | ||||||
Temperature Fluctuation | ±1℃ | ||||||
Temperature Nonuniformity Value | ±2℃ | ||||||
Timing Range | 0 to 9999min/h | ||||||
Rated Power(W) | 1000 | 1200 | 1400 | ||||
Refrigerant | R134a | R404a | |||||
Power Supply | Standard: 220V, 50Hz; Optional: 110V, 50Hz | ||||||
Shelves | 2pcs/adjustable | ||||||
Working Time | Continuous | ||||||
Outer Size (mm) | 540 X 580 X 1100 | 540 X 580 X 1220 | 590 X 630 X 1380 | 590 X 660 X 1530 | 620 X 700 X 1600 | 660 X 700 X 1700 | 720 X 760 X 1800 |
Chamber Size (mm) | 400 X 370 X 560 | 400 X 370 X 680 | 450 X 420 X 850 | 450 X 450 X 1000 | 480 X 490 X 1070 | 520 X 500 X 1170 | 580 X 540 X 1270 |
Packing Size (mm) | 680 X 730 X 1290 | 680 X 730 X 1410 | 730 X 770 X 1570 | 730 X 800 X 1720 | 760 X 850 X 1790 | 800 X 850 X 1890 | 860 X 900 X 1990 |
Gross Weight (kg) | 80 | 85 | 120 | 138 | 147 | 157 | 170 |
Standard Accessories | Socket, Light | ||||||
Optional Accessories | USB, Print | ||||||
Remarks | * The performance parameter test is under no-load conditions, the ambient temperature is 20℃; the ambient humidity is 50%RH * Cannot be used for long-term refrigeration storage |
