Foot Operated Single Scissor Mortuary Lift SMI-4019SS

CLICK TO SCAN

Features

  • Type: Electric Hydraulic  model
  • 1 scissor lifter
  • Lifting height 400 to 1700 mm
  •  Made of the Hight quality stainless steel 304
  • Trolley with Día 13cm casters, all with the brake and it is allowed for easy movement
  • Unit can be easily loaded and unloaded by one person
  • The Lock design for the body tray, avoid  the tray is off down
  • Optional height and body tray width will be according customer requirements
Previous
Next
Enquire Now

Detailed Images

Features

Technical Data

Model No.

SMI-4019SS

Adjustable Lift Height

400 to 1700 mm

Min Height

400 mm

Max Height

1700 mm

Product size

2080 X 640 X 400 mm

Body Tray Size

1940 X 580 mm

Outer Package size

2100 X 750 X 450 mm

Thickness For The Tray

1.00mm

Type

1 scissor lift

Material

Stainless Steel 304

Actuator

7000N

NW/GW

90Kg/110Kg

Load Capacity

200 Kg

Product Brochure

Product Brochure Link here
