Large Capacity Double-Door Refrigerated Shaking Incubator SMI-159LCDD

Home ≫Shakers & Shaking Incubators> Large Capacity Double-Door Refrigerated Shaking Incubator SMI-159LCDD

Large Capacity Double-Door Refrigerated Shaking Incubator SMI-159LCDD

CLICK TO SCAN

Description

JINDAL large capacity double door Refrigerated shaking incubator SMI-159LCDD for the lab has a stainless steel universal clamp, digital display temperature control, stepless speed regulation and good thermal cycle function. It is a multi purpose biochemical device, which is a plant, biology, microbiology, genetics, virus, environmental protection, medicine and other scientific research.

Main Features

  • Dual Door Reciprocating Refrigerated Shaker for Laboratory
  • Floor standing type with double piers. Stainless steel chamber with illumination.
  • Powder-coated steel construction with LCD display (with backlight) of set and working parameters.
  • Large toughened glass window to view temperature, speed and time.
  • Speed range extensible to 50-300 rpm
  • Constant temperature and refrigeration are optional
  • Timing up to 999.59 hours, with acoustic and visual alarm
  • P.I.D environmental scanning micro-processing controller with acoustic & visual alarm
  • CFC-free (134A) refrigeration system
  • High/low limit over temperature acoustic & visual alarm, high/low limit over speed alarm, stop-running
  • Protection for door opening, electric current leakage and overload protection. Motor overheat protection.
  • Automatic power cut-off in case of temperature out of control or abnormal over-temperature
  • Repeat, increment (step) and 8-segment curve programming setting
  • Power-failure recovery, parameter memory, temperature/speed calibration, time display, and room/working temperature display.
  • AC inductive long-life brushless motor, with wide speed regulation, constant torque, constant speed of rotation, and maintenance-free
  • Acceleration control circuit ensures east to start, smooth acceleration and safety of samples
  • Safety protection of automatic stop of shaking when door is opened
Previous
Next
Enquire Now

Specifications

Product
Large Capacity Double-Door Refrigerated Shaking Incubator
Model
SMI-159LCDD
Control
P.I.D.(Environmental Scanning Microprocessor)
Display
LCD(simultaneous display of working & set parameters)
Working Conditions
Temperature 25°C, RH20%-90%
Oscillation Mode
Reciprocal
Drive
Single-shaft balance device
Working Environment
Temperature: 25°C.Humidyty 20%-90%
Temp. Range
4°C-60°C
Temp. Accuracy
±0.1°C
Temp. Uniformity
±1°C
Speed Range(rpm)
50-300±1 rpm
Shaking Range
∅35
Refrigerant
R134a
Heater Power
800W
Cooler Power
230W
Tray Size(mm)
920x500
Timing Range
0-999.59hr/Continuous
Shelf Size(mm)
920x520
Shelf Qty
2PCS
Weight
356Kg
Chamber Size
1100x700x830mm
Dimensions (WxDxH,mm)
1200mm W x 850mm D x 1550mm H
Power
1340W
Power Supply
AC 200-240V/50-60Hz. Optional: AC110V/60Hz
Chamber Material
Polished stainless steel
Housing Material
Steel
